Thumbnail
R16mm Diamond Toolholder Kit
Title
R16mm Diamond Toolholder Kit
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

R16mm Toolholder is perfect size for medium to large sized lathes, 12-19 inches in swing. toolholder uses 5/16" square toolbits and features a .675" x 5/8" x 3-1/2" shank size for increased ridgidity. "R" denotes a right hand toolholder, which will cut towards lathe headstock and will do facing cuts on stock to left side of tool. Left hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

R16mm Toolholder Kit includes:
- 1 Right Hand Toolholder
- 1 HSS Tool Blank
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$165.00
Availability
Backordered
Order Code
BC61
Thumbnail
L16mm Diamond Toolholder
Title
L16mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L16mm Toolholder is perfect size for medium to large sized lathes, 12-19 inches in swing. toolholder uses 5/16" square toolbits and features a .672" x 5/8" x 3-1/2" shank size for increased ridgidity. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L16mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$135.00
Availability
Backordered
Order Code
BC258
Thumbnail
R-L16mm Diamond Toolholder Combo
Title
R-L16mm Diamond Toolholder Combo
Description

R16mm Diamond Toolholder is for large swing lathes such as Taiwanese 12" up to 20" swing. Shank is much more beefy and able to take healthy cuts in tough steel and other metals. COMBO includes new L16mm for Left-Hand cutting toward tailstock.

After grinding high speed tool blank with grinding jig, your cutting tool will be ready to mount in toolholder and begin making cuts right away.

If you're going to be doing some heavy work, or some hardened metal, you might be interested in Crobalt 5/16" square high strength toolbits -- also available on this site.

R16mm Diamond Toolholder includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instruction DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $30.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$270.00
Availability
Backordered
Order Code
BC224PKG
Thumbnail
R-L16mm Diamond Toolholder Triple Combo
Title
R-L16mm Diamond Toolholder Triple Combo
Description

New R16mm and New L16mm are bigger and tougher than old B16. L16 replaces L12 for left-hand cutting. R-L "FoR" combines Right-hand 16mm and Left-hand 16mm Diamond Toolholders with "FoR" (Front or Rear) Parting Tool, so when all turning, facing, cutting to a shoulder and screw thread forming is finished, you have "FoR" tool ready to remove your work cleanly and quickly from lathe. Only requirement for your lathe is that it be operated in reverse. FoR 12 includes high strength Crobalt parting tool blade, so cut will be clean and precise.

R-L FoR 16mm Triple COMBO includes:
-1 Right Hand Toolholder
-1 Left Hand Toolholder
-2 HSS Tool Blanks
-1 Grinding Jig
-1 Hex Key
-1 Crobalt Cutoff Blade
-1 FoR 16mm Parting Tool
-1 Instructional DVD
-Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $68.00 versus what you would have paid by buying each tool separately.

If backordered shipping may take two to three weeks


Price
$405.00
Availability
Backordered
Order Code
BC223PKG
Thumbnail
R20mm Diamond Toolholder Kit
Title
R20mm Diamond Toolholder Kit
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

R20mm Toolholder is perfect size for heavy-duty lathes capable of using 3/4" tooling. Toolholder uses 5/16" square toolbits and features a 3/4" x 3/4" shank size for increased ridgidity. "R" denotes a right hand toolholder, which will cut towards lathe headstock and will do facing cuts on stock to left side of tool. Left hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

R20mm Toolholder Kit includes:
- 1 Right Hand Toolholder
- 1 HSS Tool Blank
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$170.00
Availability
In Stock
Order Code
BC254
Thumbnail
L20mm Diamond Toolholder
Title
L20mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L20mm Toolholder is perfect size for heavy-duty lathes capable of using 3/4" tooling. Toolholder uses 5/16" square toolbits and features a 3/4" x 3/4" shank size for increased ridgidity. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L20mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$135.00
Availability
In Stock
Order Code
BC255
Thumbnail
R-L20mm Diamond Toolholder Combo
Title
R-L20mm Diamond Toolholder Combo
Description

20mm Toolholders are designed for heavier duty work on lathes using 20mm or 3/4" tooling.

holders take both 5/16" and 8mm tools bits (square or round) as standard, but also have ability to use 1/4" or 6mm tool bits, using alternative clamp that can be purchased separately.

Smaller tool bits are more cost effective if you are normally taking cuts less than 6mm deep, they are also quicker to re-sharpen. Same grinding jig is able to sharpen 5/16", 1/4", 8mm, and 6mm tool bits.

Tool size will depend on a combination of size of your lathe and type of tool post fitted, Check tool height and size of tool post slot in your lathe before purchasing.

20mm Toolholders include:
- 1 Left Hand Toolholder
- 1 Right Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instruction sheet

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $35.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$270.00
Availability
In Stock
Order Code
BC256PKG
Thumbnail
R-L20mm Diamond Toolholder Triple Combo
Title
R-L20mm Diamond Toolholder Triple Combo
Description

New R20mm and New L20mm are bigger and tougher than old B20. L20 replaces L20 for left-hand cutting. R-L "FoR" combines Right-hand 16mm and Left-hand 20mm Diamond Toolholders with "FoR" (Front or Rear) Parting Tool, so when all turning, facing, cutting to a shoulder and screw thread forming is finished, you have "FoR" tool ready to remove your work cleanly and quickly from lathe. Only requirement for your lathe is that it be operated in reverse. FoR 12 includes high strength Crobalt parting tool blade, so cut will be clean and precise.

R-L FoR 20mm Triple COMBO includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Crobalt Cutoff Blade
- 1 FoR 20mm Parting Tool
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $70.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$410.00
Availability
In Stock
Order Code
BC283PKG
Thumbnail
R25mm Diamond Toolholder Kit
Title
R25mm Diamond Toolholder Kit
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

R25mm Toolholder is perfect size for heavy-duty lathes capable of using 1" tooling. Toolholder uses 5/16" square toolbits and features a 1" x 1" shank size for increased ridgidity. "R" denotes a right hand toolholder, which will cut towards lathe headstock and will do facing cuts on stock to left side of tool. Left hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

R25mm Toolholder Kit includes:
- 1 Right Hand Toolholder
- 1 HSSTool Blank
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$180.00
Availability
Backordered
Order Code
BC263
Thumbnail
L25mm Diamond Toolholder
Title
L25mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L25mm Toolholder is perfect size for heavy-duty lathes capable of using 1" tooling. Toolholder uses 5/16" square toolbits and features a 1" x 1" shank size for increased ridgidity. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L25mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$145.00
Availability
In Stock
Order Code
BC265
Thumbnail
R-L25mm Diamond Toolholder Combo
Title
R-L25mm Diamond Toolholder Combo
Description

25mm Toolholders are designed for heavier duty work on lathes using 25mm or 3/4" tooling.

Holders take both 5/16" and 8mm tools bits (square or round) as standard, but also have ability to use 1/4" or 6mm tool bits, using alternative clamp that can be purchased separately.

Smaller tool bits are more cost effective if you are normally taking cuts less than 6mm deep, they are also quicker to re-sharpen. Same grinding jig is able to sharpen 5/16", 1/4", 8mm, and 6mm tool bits.

Tool size will depend on a combination of size of your lathe and type of tool post fitted, Check tool height and size of tool post slot in your lathe before purchasing.

25 mm Toolholders include:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $30.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$295.00
Availability
Backordered
Order Code
BC267PKG
Thumbnail
Crobalt Cutoff Blade for FoR Parting Tool
Title
Crobalt Cutoff Blade for FoR Parting Tool
Description

The FoR holder takes the common 1/2" x 3/32" tapered type parting blade, these also have a bevel on the top and bottom so that they lock securely into a holder.

The FoR Parting Tool Holder does not include a blade in the purchase, but these are widely available from several manufacturers and many suppliers worldwide. The blade is easily sharpened on any bench grinder and instructions for setting up, sharpening, and tips for best results, are included with the holder.

Blades are double bevel for use in Brown and Sharpe type holders. Can be used in either a right hand or a left hand holder.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action


Price
$70.00
Availability
Backordered
Order Code
BC210
Thumbnail
FoR 8mm Parting Tool
Title
FoR 8mm Parting Tool
Description

The FoR Inverted Parting Toolholder operates with the blade held in an upside down position and can be used on front or rear tool posts.

For lathes with a screw on chuck the holder must be used with a rear tool post.

Parting blade not included.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action


Price
$95.00
Availability
Backordered
Order Code
BC230
Thumbnail
FoR 8mm Parting Tool Combo
Title
FoR 8mm Parting Tool Combo
Description

The FoR (Front or Rear) Inverted Parting Toolholder INCLUDES a fine, high-strength Crobalt parting tool. The FoR operates with the blade held upside down and can be used in a front or rear tool post.

This model is specifically set for toolposts that accommodate the 8mm Diamond Toolholder.

ADVANTAGES:

1: The inverted blade design significantly reduces the chance of a jam-up and blade breakage.

2: Minimal side overhang and no front overhang help maximize rigidity.

3: Cutting takes place on the underside so swarf will tend to fall out of the groove rather than pile up on top of the cutting edge.

4: The lack of swarf on top of the blade means coolant is free to get right in to the cutting edge.

5: The horizontal mounting of the blade further reduces the chance of the blade pulling itself into the cut and is especially advantageous when turning brass and bronze.

6: Simple to resharpen as only the front face has to be ground.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?


Price
$150.00
Availability
Backordered
Order Code
BC236PKG
Thumbnail
FoR 9.5mm Parting Tool
Title
FoR 9.5mm Parting Tool
Description

The FoR Inverted Parting Toolholder operates with the blade held in an upside down position and can be used on front or rear tool posts.

For lathes with a screw on chuck the holder must be used with a rear tool post.

Parting blade not included.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action


Price
$95.00
Availability
Backordered
Order Code
BC269
