Thumbnail
L9.5mm Diamond Toolholder
Title
L9.5mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L9.5mm Toolholder is perfect size for smaller, 9-12 inch lathes such as South Bend 9 or Logan 10. Toolholder uses 1/4" square toolbits and features a 1/2" x 1/2" shank size. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L9.5mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$115.00
Availability
Backordered
Order Code
BC60
Thumbnail
R-L9.5mm Diamond Toolholder Combo
Title
R-L9.5mm Diamond Toolholder Combo
Description

R-L9.5 is proper size for lathes with 9" to 12" swing, e.g. Logan 9", South Bend 9", etc.

HSS tool bit size - 1/4" x 1/4" x 38mm (1 1/2") M42 grade 8% Cobalt

Shank size (HWL) - 12.7 mm x 12mm x 76mm (1/2" x 15/32" x 3")

Minimum tool height - 9.5mm (3/8")

Distance from shank to tool tip - 32mm (1 1/4")

Clamp screw - M5

R-L9.5mm Diamond Toolholder Combo includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $25.00 versus what you would have paid by buying each tool separately.

If backordered shipping may take two to three weeks


Price
$240.00
Availability
Backordered
Order Code
BC264PKG
Thumbnail
R-L9.5mm Diamond Toolholder Triple Combo
Title
R-L9.5mm Diamond Toolholder Triple Combo
Description

R-L9.5 combines Right and Left-hand 9.5 Diamond Toolholders with "FoR" (Front or Rear) 9.5mm Parting Tool, so when all turning, facing, cutting to a shoulder and screw thread forming is finished, you have FoR tool ready to remove your work cleanly and quickly from lathe. Only requirement for your lathe is that it be operated in reverse. FoR includes high strength Crobalt parting tool blade, so cut will be clean and precise. This new parting tool is exactly proper size (9.5mm) to work in your toolpost, and line up with your workpiece.

R-L FoR 9.5mm Triple COMBO includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Crobalt Cutoff Blade
- 1 FoR 9.5mm Parting Tool
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $73.00 versus what you would have paid by buying each tool separately.

If backordered shipping may take two to three weeks


Price
$365.00
Availability
Backordered
Order Code
BC237PKG
Thumbnail
R12mm Diamond Toolholder Kit
Title
R12mm Diamond Toolholder Kit
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

R12mm Toolholder is perfect size for 7-12 inch lathes and it works well with toolpost heights found on most Asian imports. Toolholder uses 1/4" square toolbits and features a 15/32" x 19/32" shank size. "R" denotes a right hand toolholder, which will cut towards lathe headstock and will do facing cuts on stock to left side of tool. Left hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

R12mm Toolholder Kit includes:
- 1 Right Hand Toolholder
- 1 HSS Tool Blank
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$155.00
Availability
Backordered
Order Code
BC194
Thumbnail
L12mm Diamond Toolholder
Title
L12mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L12mm Toolholder is perfect size for 7-12 inch lathes and it works well with toolpost heights found on most Asian imports. Toolholder uses 1/4" square toolbits and features a 15/32" x 19/32" shank size. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L12mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$115.00
Availability
Backordered
Order Code
BC195
Thumbnail
R-L12mm Diamond Toolholder Combo
Title
R-L12mm Diamond Toolholder Combo
Description

R-L12mm Combo Diamond Toolholders are designed to operate on oversized toolposts on Asian Mini-Lathes now being sold in thousands. These toolholders consist of:

HSS tool bit size - 1/4" x 1/4" x 32mm (1 1/2") M42 grade 8% Cobalt

Right/Left Diamond Toolholder Combo for 12mm units consist of:

Shank size (HWL) - 15mm x 12mm x 76mm (19/32" x 15/32" x 3")

Minimum tool height - 12mm (15/32")

Distance from shank to tool point - 32mm (1 1/4")

Clamp screw - M5

R-L12mm Diamond Toolholder Combo includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $25.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$245.00
Availability
Backordered
Order Code
BC200PKG
Thumbnail
R-L12mm Diamond Toolholder Triple Combo
Title
R-L12mm Diamond Toolholder Triple Combo
Description

R-L12mm Combo Diamond Toolholders are designed to operate on oversized toolposts on Asian Mini-Lathes now being sold in thousands.

Right/Left Diamond Toolholder Combo for 12mm units: Shank size (HWL) 15mm x 12mm x 76mm (19/32" x 15/32" x 3".)

Minimum tool height - 12mm (15/32".)

Distance from shank to tool point-32mm (1 1/4".)

Clamp screw - M5.

Triple Combo includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 1 FoR Parting Tool
- 1 Crobalt Cutoff Blade
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $63.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$380.00
Availability
Backordered
Order Code
BC260PKG
Thumbnail
R16mm Diamond Toolholder Kit
Title
R16mm Diamond Toolholder Kit
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

R16mm Toolholder is perfect size for medium to large sized lathes, 12-19 inches in swing. toolholder uses 5/16" square toolbits and features a .675" x 5/8" x 3-1/2" shank size for increased ridgidity. "R" denotes a right hand toolholder, which will cut towards lathe headstock and will do facing cuts on stock to left side of tool. Left hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

R16mm Toolholder Kit includes:
- 1 Right Hand Toolholder
- 1 HSS Tool Blank
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$165.00
Availability
Backordered
Order Code
BC61
Thumbnail
L16mm Diamond Toolholder
Title
L16mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L16mm Toolholder is perfect size for medium to large sized lathes, 12-19 inches in swing. toolholder uses 5/16" square toolbits and features a .672" x 5/8" x 3-1/2" shank size for increased ridgidity. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L16mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$135.00
Availability
Backordered
Order Code
BC258
Thumbnail
R-L16mm Diamond Toolholder Combo
Title
R-L16mm Diamond Toolholder Combo
Description

R16mm Diamond Toolholder is for large swing lathes such as Taiwanese 12" up to 20" swing. Shank is much more beefy and able to take healthy cuts in tough steel and other metals. COMBO includes new L16mm for Left-Hand cutting toward tailstock.

After grinding high speed tool blank with grinding jig, your cutting tool will be ready to mount in toolholder and begin making cuts right away.

If you're going to be doing some heavy work, or some hardened metal, you might be interested in Crobalt 5/16" square high strength toolbits -- also available on this site.

R16mm Diamond Toolholder includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instruction DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $30.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$270.00
Availability
Backordered
Order Code
BC224PKG
Thumbnail
R-L16mm Diamond Toolholder Triple Combo
Title
R-L16mm Diamond Toolholder Triple Combo
Description

New R16mm and New L16mm are bigger and tougher than old B16. L16 replaces L12 for left-hand cutting. R-L "FoR" combines Right-hand 16mm and Left-hand 16mm Diamond Toolholders with "FoR" (Front or Rear) Parting Tool, so when all turning, facing, cutting to a shoulder and screw thread forming is finished, you have "FoR" tool ready to remove your work cleanly and quickly from lathe. Only requirement for your lathe is that it be operated in reverse. FoR 12 includes high strength Crobalt parting tool blade, so cut will be clean and precise.

R-L FoR 16mm Triple COMBO includes:
-1 Right Hand Toolholder
-1 Left Hand Toolholder
-2 HSS Tool Blanks
-1 Grinding Jig
-1 Hex Key
-1 Crobalt Cutoff Blade
-1 FoR 16mm Parting Tool
-1 Instructional DVD
-Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $68.00 versus what you would have paid by buying each tool separately.

If backordered shipping may take two to three weeks


Price
$405.00
Availability
Backordered
Order Code
BC223PKG
Thumbnail
R20mm Diamond Toolholder Kit
Title
R20mm Diamond Toolholder Kit
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

R20mm Toolholder is perfect size for heavy-duty lathes capable of using 3/4" tooling. Toolholder uses 5/16" square toolbits and features a 3/4" x 3/4" shank size for increased ridgidity. "R" denotes a right hand toolholder, which will cut towards lathe headstock and will do facing cuts on stock to left side of tool. Left hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

R20mm Toolholder Kit includes:
- 1 Right Hand Toolholder
- 1 HSS Tool Blank
- 1 Grinding Jig
- 1 Hex Key
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$170.00
Availability
In Stock
Order Code
BC254
Thumbnail
L20mm Diamond Toolholder
Title
L20mm Diamond Toolholder
Description

Diamond Toolholder's unique design provides a number of benefits over standard tooling, both in use and when sharpening. When cutting, 80 degree included angle of tool allows machinist to both turn and face in same setup, saving time and tooling. When it comes time to sharpen toolbit, simply clamp it in sharpening jig (supplied with Right Hand Toolholder kit) and grind. That's all there is to sharpening toolbit -- no complicated geometry, only one face needs grinding. Get prefect results every time!

L20mm Toolholder is perfect size for heavy-duty lathes capable of using 3/4" tooling. Toolholder uses 5/16" square toolbits and features a 3/4" x 3/4" shank size for increased ridgidity. "L" denotes a left hand toolholder, which will cut towards lathe tailstock and will do facing cuts on shoulders to right side of tool. Right hand toolholders are also available.

Tool holder size will depend on a combination of size of your lathe and type of tool post fitted. Model number indicates distance in millimeters from bottom of tool post tool slot to lathe centerline. Check tool height and size of tool slot in tool post before purchasing.

L20mm Toolholder includes:
- 1 Left Hand Toolholder
- 1 HSS Tool Blank

NOTE: This model includes the HSS tool blank only, assuming you already own Right Hand Diamond Toolholder, which comes with a Hex Key, Grinding Jig, DVD, and HSM article reprints.

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

If backordered, shipping may take two to three weeks


Price
$135.00
Availability
In Stock
Order Code
BC255
Thumbnail
R-L20mm Diamond Toolholder Combo
Title
R-L20mm Diamond Toolholder Combo
Description

20mm Toolholders are designed for heavier duty work on lathes using 20mm or 3/4" tooling.

holders take both 5/16" and 8mm tools bits (square or round) as standard, but also have ability to use 1/4" or 6mm tool bits, using alternative clamp that can be purchased separately.

Smaller tool bits are more cost effective if you are normally taking cuts less than 6mm deep, they are also quicker to re-sharpen. Same grinding jig is able to sharpen 5/16", 1/4", 8mm, and 6mm tool bits.

Tool size will depend on a combination of size of your lathe and type of tool post fitted, Check tool height and size of tool post slot in your lathe before purchasing.

20mm Toolholders include:
- 1 Left Hand Toolholder
- 1 Right Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Instruction sheet

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $35.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$270.00
Availability
In Stock
Order Code
BC256PKG
Thumbnail
R-L20mm Diamond Toolholder Triple Combo
Title
R-L20mm Diamond Toolholder Triple Combo
Description

New R20mm and New L20mm are bigger and tougher than old B20. L20 replaces L20 for left-hand cutting. R-L "FoR" combines Right-hand 16mm and Left-hand 20mm Diamond Toolholders with "FoR" (Front or Rear) Parting Tool, so when all turning, facing, cutting to a shoulder and screw thread forming is finished, you have "FoR" tool ready to remove your work cleanly and quickly from lathe. Only requirement for your lathe is that it be operated in reverse. FoR 12 includes high strength Crobalt parting tool blade, so cut will be clean and precise.

R-L FoR 20mm Triple COMBO includes:
- 1 Right Hand Toolholder
- 1 Left Hand Toolholder
- 2 HSS Tool Blanks
- 1 Grinding Jig
- 1 Hex Key
- 1 Crobalt Cutoff Blade
- 1 FoR 20mm Parting Tool
- 1 Instructional DVD
- Helpful articles written by Rudy Kouhoupt & Desmond Burke

Diamond Toolholders Features and Tips | Toolholder in Action
FoR Inverted Parting Toolholder Features and Tips | Toolholder in Action
What Size Do I Need? | Right or Left Handed?

By buying this combo, you're saving a total of $70.00 versus what you would have paid by buying each tool separately.

If backordered, shipping may take two to three weeks


Price
$410.00
Availability
In Stock
Order Code
BC283PKG
